Fabricated & Custom Strainer Products



We can engineer, design and fabricate a strainer to satisfy a specific requirement. The items illustrated below represent only a few of the almost limitless fabricated shapes and sizes of strainers which we can supply.

  • Simplex & Duplex Strainers
  • Bag Filter Housings
  • Pleated Strainers
  • Suction Strainer
  • Custom Products
Simplex Strainer 1

Fabricated Stainless Steal 316 simplex strainers.


Simplex Strainer 1

Fabricated Carbon Steel Simplex Strainer with Davit Arm.


Simplex Strainer 1

Model No. FSX-43FSS-316, size 3.0 inch inlet/outlet connection stainless steel 316 simplex strainers class 150# raised face flanged with bolted covers.


Simplex Strainer 6

Fabricated Strainers Size 6.0 Stainless Steel 317 #150lb Flange with quick opening eye bolt closure


Simplex Strainer 2

10.0" fabricated carbon steel simplex strainer with 150# raised faced flange with bolted cover and supporting legs and stainless steel basket.


Simplex Strainer 3

Are available with pipe connections of 1/2 inch through 12.0 inch NPT or flanged. Housing can be furnished in carbon steel, stainless steel, Aluminium and monel, hastelloy C, etc. Large basket capacity for less frequent cleaning. optional filter bags.


Simplex Strainer 5

Stainless steel 316 clamp covered simplex strainers.


Simplex Strainer 8

Size 6.0" carbon steel flanged simplex strainer.


Simplex Strainer 10

Custom fabricated stainless steel simplex strainers.


Simplex Strainer 12

Carbon steel fabricated simplex strainers.


Simplex Strainer 13

Stainless steel sanitized simplex strainers.


Simplex Strainer 14

Stainless steel fabricated high pressure strainers with bolted cover.

RELATED PRODUCTS
Slanted Basket 7

Simplex Strainer 15

Fabricated simplex strainer with bolted cover.


Simplex Strainer 17

Fabricated 4", 150lb flange simplex strainer, Teflon coated on the inside with wedge-wire basket.


Simplex Strainer 4

Stainless steel number 1 and number 2 filter bag housings sizes from 1.0" NPT to 3.0" NPT with dome or flat type perforated bottoms.


Simplex Strainer 6

2.0" Stainless steel filter bag housings with swing away covers.


Simplex Strainer 7

No 2 flanged filter bag housing.


Simplex Strainer 9

Clamp cover No 4. filter bag housing.


Simplex Strainer 11<

Stainless steel clamped cover No. 2 filter bag housing.


Simplex Strainer 17

Fabricated 4", 150lb flange simplex strainer, Teflon coated on the inside with wedge-wire basket. No. 1 size filter bag housing with wedge-wire basket to utilize as a strainer.


Are available 1 inch through 48 inch with solid or perforated bottoms.

For detailed drawings please click on downloadable PDF files below.

Suction Strainer 6

Stainless steel 150# ANSI flanged discharged pump strainers with pleated stainless steel perforated material.


Pleated Striner 1

Pleated 400 mesh (38 micron) suction strainers.


Pleated Strainer 1>

Automatic Strainer.


Perforated Lobster Pots convoluted mesh lined stainless steel baskets


Pleated Strainer 3

Lobster pot style convoluted fabricated stainless steel strainers for 10, 12, 16, and 18 inch Hayward model 72-73 simplex strainers and model 50-51 duplex strainers, lined with or without stainless steel mesh. Also available in Monel material.

RELATED PRODUCTS
Replacement Basket 1

Are available 1 inch through 48 inch with solid or perforated bottoms.

For detailed drawings please click on downloadable PDF files below.

Suction Strainer 1

8 inch 150lbs Flange 316 Stainless Steel Suction Strainer half inch perforation with supported perforated Bottom.


Suction Strainer 1

Size 3" Female Coupling all SS 316 Suction Strainers solid one end and perforated on other end.


Suction Strainer 1

Stainless Steal 16in suction strainer with inner cage built inside.


Suction Strainer 1

1.0 inch perforation size, 316 stainless steel discharge pump strainers.


Suction Strainer 2

300 lbs flanged stainless steel 1/8" perforated strainers.


Suction Strainer 3

Perforated Monel and Copper discharge pump strainers with all welded Monel and Bronze female couplings.


Suction Strainer 4

Material of construction: zinc plated steel, stainless steel, monel, hastelloy, etc. Perforated 1/32" to 1.0" diameter holes.


Suction Strainer 5

Fabricated Discharge Pump Strainers. Pump strainer with full or half female coupling.


Suction Strainer 6

Stainless steel 150# ANSI flanged discharged pump strainers with pleated stainless steel perforated material.


Suction Strainer 7

4.0" stainless steel 1/8" perforated with 1/2 female coupling and perforated bottom.


Suction Strainer 8

Pleated 400 mesh (38 micron) suction strainers.

RELATED PRODUCTS
Pleated Strainer 1

Suction Strainer 9

3.0" stainless steel 1/4" perforated discharge pump strainers.


Suction Strainer 10

Titanium male connector suction strainers.


Suction Strainer 11

316 stainless steel wedge wires suction strainer with 1.5" male connection.


Suction Strainer 12

All Stanless steel heavy duty suction strainer with 16" flange.


Suction Strainer 12

All Stanless steel reinforced heavy duty suction strainer.


Custom Product 1

Fabricated Stainless Steal Y type strainers.


Custom Product 1

Heavy Duty Double Element Screens


Custom Product 1

Pipe drainage baskets for 10 & 12 inch pipes in 3/16 perforated holes, 316 stainless steel material.


Suction Strainer 6

Large size fabricated perforated baskets with cage built Inside for extra support


Custom Product 16

Tate and Dale replacement basket with custom stainless steel flange used to replace old cast iron flange for a stonger and longer lasting basket.


Custom Product 1

Size 10 inch Bell and Gosset Screens with Baffles


Perforated Lobster Pots convoluted mesh lined stainless steel baskets


Custom Product 1

Long Stainless Steel Perforated Basket Strainers with Extra Support


Custom Product 1

1/4 inch perforated stainless steel cylinders with support beams built inside for extra rigidity. Used in "Y" type strainers.

RELATED PRODUCTS
Perforated Tube 1

Custom Product 2

Special designed perforated strainers with stainless steel attachments.


Custom Product 3

316 stainless steel 1/4" perforated strainers, 8.0 feet long x 6.0 inch diameter.


Custom Product 4

Perforated stainless steel and carbon steel basket strainers with perforated bottoms and removable solid covers.


Custom Product 6

Stainless steel 316 grooved flange basket strainers with 1/2" perforated material.


Custom Product 7

Heavy duty stainless steel drainage baskets.


Custom Product 8

Stainless steel heavy duty reinforced basket strainers with mesh liner used in machine shop industry for collecting metal particles.


Custom Product 9>

All monel perforated baskets with monel mesh liner.


Custom Product 10

Fabricated stainless steel housing with perforated basket.


Custom Product 11

Lobster pot style convoluted fabricated stainless steel strainers for 10, 12, 16, and 18 inch Hayward model 72-73 simplex strainers and model 50-51 duplex strainers, lined with or without stainless steel mesh. Also available in Monel material.

RELATED PRODUCTS
Pleated Striner 1

Custom Product 12

Stainless steel baskets with zinc plated attachment


Custom Product 13

Special custom cone strainer.


Custom Product 14

Teflon coated strainers.


Custom Product 15

Stainless steel electro polished eliptical 1/2' perforated stainers.


Custom Product 16

1/4 perforated basket strainers.


Custom Product 17

Monel heavy duty 1/4" Thick material with water jet 1/8" perforation.
